Wake-on LAN.

Or: The Magic of Magic Packets.

Wake-on LAN.


Wake-on LAN (WoL), where LAN stands for Local Area Network, allows me to power up a remote computer using a network command. This is possible thanks to a "Magic Packet". To enable this feature, I need to configure the BIOS/UEFI, install a few tools, and create a persistent WoL service on the remote PC.

An Introduction.

Modern network cards support a feature called Wake-on LAN, sometimes known as WoL. There is also some support for WoWLAN, or Wake-on Wireless LAN.

Wireless LAN is commonly called WiFi.

Wake-on LAN is the process of, under specific conditions, causing a PC to turn on when commanded to do so by another PC. Wake-on LAN uses a Magic Packet that the remote NIC recognises as the Wake-on command. When the Magic Packet is received, the remote NIC tells the attached PC to begin its boot process. Although generating a Wake-on Magic Packet is commonly thought of as an Ethernet LAN feature, it is also possible to execute this command over WiFi or the Internet. These options are only possible under very specific conditions, e.g. the Internet option needs a router that supports Port 7 or Port 9 UDP forwarding of the Magic Packet, as well as settings that are beyond the scope of this post.

The purpose of this post is to present the process of setting up, and using the WoL (Wake-on LAN) and WoWLAN (Wake-on Wireless LAN) features available over Ethernet and WiFi LANs - Local Area Networks.

The Big Picture.

Most people are lazy, but programmers are also motivated by automation. This combination of "using machines to do the heavy lifting" (figuratively and literally) while expending the least amount of energy is what separates your common dawdler from a consummate developer.

Computer programmers are lazy, but we also get things done. Or, more precisely, we build the automated processes that are used to get things done on command.

Case in point: I will deploy a service that lets me turn on a LAN-connected computer without needing to stand up, cross the room, and press a power button.

Wired vs WiFi.

Personally, I'd prefer running CAT-6a cables to every PC. However, I've started my company in a rental flat (where a flat is called an apartment in other parts of the world) so there are hard limits to what I can alter in someone else's property. I run Ethernet cables where I can. Otherwise, I resort to WiFi as a (poor) substitute.

Enabling the WoL Service on a Remote PC.

NOTE: This procedure automatically deletes itself when the remote PC reboots.

  • I enable the 'Wake-on LAN' setting in the BIOS/UEFI.

  • I update and upgrade the remote PC:

sudo apt clean && sudo apt update && sudo apt dist-upgrade -y && sudo apt autoremove -y
  • I install the ethtool on the remote PC:
sudo apt install ethtool
  • I display the NIC name (e.g. eno1, enp6s0, etc.):
ip a

NOTE: I typically have two entries. The 'lo' entry is the local loopback with the IP address. The name of the other entry is what I need, e.g. eno1.

  • I check the network card settings (to determine the status of 'Supports Wake-on' and 'Wake-on') given the NIC is called eno1:
sudo ethtool eno1

NOTE: 'pumbg' means that using a Magic Packet is supported, 'g' means Wake-on is enabled, and 'd' means Wake-on is disabled.

  • I enable the Wake-on LAN feature:
sudo ethtool --change eno1 wol g
  • I can also disable the Wake-on LAN feature if required:
sudo ethtool --change eno1 wol d

Persisting the WoL Service on a Remote PC.

NOTE: This procedure persists the WoL settings between PC reboots.

  • I check if, and where, the ethtool is installed:
which ethtool
  • I install the ethtool on the remote PC if required:
sudo apt install ethtool
  • I create a wol.service file:
sudo touch /etc/systemd/system/wol.service
  • I open the wol.service file in Nano:
sudo nano /etc/systemd/system/wol.service
  • I add the following into the wol.service file:
Description=Enable Wake On Lan

ExecStart = /usr/sbin/ethtool --change eno1 wol g

  • I save (CTRL+S) the changes to the wol.service file and exit (CTRL + X) the Nano editor.

  • I change the wol.service file permissions if required:

sudo chmod 600 /etc/systemd/system/wol.service
  • I restart the daemon:
sudo systemctl daemon-reload
  • I enable the wol.service:
sudo systemctl enable wol.service

NOTE: The wol.service will now start on boot.

  • I reboot the PC:
sudo reboot
  • After the remote PC reboots, I check the network card settings to ensure the 'Supports Wake-on' and 'Wake-on' are both set to 'g':
sudo ethtool eno1

I display the MAC address of the remote NIC (which I'll use in the next section):

ip a

NOTE: The MAC address is displayed in the 'link/ether' setting.

  • I power down the system:
sudo poweroff

Waking a PC over Ethernet.

NOTE: This procedure only works over ethernet connections across the same LAN.

  • I update and upgrade the local PC:
sudo apt clean && sudo apt update && sudo apt dist-upgrade -y && sudo apt autoremove -y
  • On the local PC, within the same LAN, I install etherwake:
sudo apt install etherwake
  • I send a WoL Magic Packet to the MAC address of the remote NIC:
wakeonlan 01:23:89:ab:cd:ef

The Results.

Wake-on LAN is a fantastic tool for powering on remote computers, which saves me time and minimises my efforts. By enabling WoL on a remote PC, I can control the power state of that device using an Ethernet or WiFi connection. With the right configuration, WoL and WoWLAN can be valuable assets to my LAN.

In Conclusion.

Here's what I know: A good programmer:

  • Is lazy,

  • Automates whatever he can, and

  • Solves any problems that happen to pop up.

I'm not a great programmer, but I'm SUPER-QUALIFIED for any position where laziness is a requirement.

Until next time: Be safe, be kind, be awesome.
